| Model |
|
PE-104 |
PE-104 |
| Type |
|
without platform |
without platform |
| Capacity |
kg |
2000 |
2000 |
| Load Center |
C (mm) |
600 |
600 |
| Max. Fork Height |
H (mm) |
205 |
205 |
| Min. Fork Height |
H (mm) |
85 |
85 |
| Fork Length |
L1 (mm) |
1150 |
1150 |
| Individual Fork Width |
b (mm) |
160 |
160 |
| Wheel Base |
y (mm) |
1406 |
1406 |
| Turning Radius |
Wa (mm) |
1608 |
1946 |
| Traveling Speed With/Without Load |
(Km/h) |
3.6/5.4 |
3.6/5.4 |
| Lifting Speed With/Without Load |
(mm/s) |
22/32 |
22/32 |
| Lowering Speed With/Without Load |
Wa (mm) |
50/55 |
50/55 |
| Drive Wheel |
|
1200W, Ø250mm (AC) |
1200W, Ø250mm (AC) |
| Power Unit (lifting motor) |
(W/V) |
800/24 |
800/24 |
| Traction Battery |
|
24V/210Ah, 185kg |
24V/210Ah, 185kg |
| Battery Charger |
|
25A/24V |
25A/24V |
| Overall Dimension (L×W×H) |
(mm) |
1781×690×1305 |
2125×690×1305 |
| Fork Overall Width |
B (mm) |
530 | 680 |
530 | 680 |
| Net Weight |
(kg) |
324 | 329 |
338 | 343 |
| Tiller |
|
O | O |
O | O |
